Curving Machines
|
Size |
1500*850*2000mm |
|
Weight |
500KGS |
|
Voltage |
380V/50HZ/3PH |
|
Motor Power |
4KW |
|
Hydraulic Power |
3KW |
|
Motor for changing models Power |
0.37KW |
|
Curved Thickness for Aluminum |
0.8-1.2mm |
|
Curved Thickness for Steel |
0.7-1.0mm |
|
Width of straight roofing to curve |
300mm to 600mm |
|
Min.Width of Tapered Roofing to Curved |
250mm |
|
Max.Width of Tapered Roofing to Curved |
500mm |
|
Working Speed |
10-16m/min |
|
Forming Steps |
3 steps |
|
Min. Curved Radius for Al Roof |
Convex Curved 1M, Concave Curved 6M |
|
Min.Curved Radius for Steel Roof |
Convex Curved 4M, Concave Curved 8M |
|
Min.Curved Radius for Tapered Al Roof |
Convex Curved 8M, Concave Curved 12M |
|
Min.Curved Radius for Tapered Steel Roof |
Convex Curved 10M, Concave Curved 14M |
|
Painted Color |
Blue or Customization |
