Machine components:
Manual Uncoiler-------------------------------1unit
Roll forming device----------------------------1unit
Cutting device----------------------------------1unit
Pressing device--------------------------------1unit
Control system---------------------------------1unit
Hydraulic station-------------------------------1unit
Output table------------------------------------1unit
Techincal description:
| Decoiler | Inner Diameter: Φ508 – Φ600 mm Out Diameter: 1500 mm Max. Loading Capacity: 5000 kgs |
| Roll forming device |
Thickness of the plate : 0.3-0.8mm Input width of the plate: 1000mm Output width of the plate :828mm (adjustable as differnent profile drawing) Productivity :8-12m/min Roller steps :14 rows Roller material: 45# steel Diameter of active shaft: 80mm Roller Material: 45# steel Rolling chromium thickness:0.05 mm Main power:4kw Wall thickness of the main forming machine: 16mm steel plate Main forming machine body : 300mmH steel Transmission chain is 1'' |
| Pressing Die |
It adopts hydraulic drive and automatic location to decide the dimention and press the target products. Stop to press, Post to press Press tool material: 40Cr and heat-treated |
| Cutting device | It adopts hydraulic drive and automatic location to decide the dimention and cut the target products.
Hydraulic power:5.5kw Cutting length tolerance: ±2mm Cutting tool material: GCr12 with quenched treatment 55-60°C |
| Control system | Type: PLC Frequency Control System with touch screen PLC Brand: Japan Panasonic Encoder Brand: Omron Length Error:±2mm |
| Output table |
It is simple and used to load finished product. Length:6m |
